19mic Low Temperature Cross Linked Film
YJ117
Low temperature cross Linked film is a kind of high transparency, excellent sealing strength and soft shrinkage film, which has the characteristics of low shrinkage and can shrink quickly at low temperature,it is Ideal heat shrink film for packaging chocolate and other products. The effect of low temperature shrinkage can also protect the heat sensitive products,it is suitable for all types shrinking machines.
Delivery:
EXW, FOB, CIF, DDU
Minimum order quantity:
20 kilograms
Supply Ability:
1000kilograms / Day
Country of Origin:
China
Stock Time:
5Day
Quantity
| Product Name | Low Temperature Cross Linked Shrink Film | ||||
| Color | Transparent | ||||
| Available thickness | 12,15,19um | ||||
| Type | Perforated No-perforated | ||||
| Available width | Single Wound:200mm-3200mm Center Folded:150mm-1000mm | ||||
| MOQ | 2000kg | ||||
| Delivery time | 7-10days/20GP,10-15days/40GP | ||||
| Packing | One roll in one box,all boxes will be packed with plywood pallets | ||||
| Application | Low temperature cross Linked film is a kind of high transparency, excellent sealing strength and soft shrinkage film, which has the characteristics of low shrinkage and can shrink quickly at low temperature,it is Ideal heat shrink film for packaging chocolate and other products. The effect of low temperature shrinkage can also protect the heat sensitive products,it is suitable for all types shrinking machines. | ||||
| Physical Properties | |||||
| Test Item | Unit | Astm Test | Typical Values | ||
| THICKNESS | μm | 12 | 15 | 19 | |
| OPTICS | |||||
| Haze | D1003 | 2 | 2.2 | 2.4 | |
| Gloss @ 45Deg | D2457 | 80 | |||
| Clarity | D1746 | 90.1 | |||
| SHRINKAGE PROPERTIES | MD | TD | |||
| Free Shrinkage 90℃ | % | D2732 | 20 | 25 | |
| 100℃ | 35 | 40 | |||
| 110℃ | 59 | 60 | |||
| 120℃ | 78 | 79 | |||
| TENSILE | |||||
| Tensile Strength(MD) | N/mm² | D882 | 100 | ||
| Tensile Strength(TD) | 100 | ||||
| Elongation(MD) | % | 110 | |||
| Elongation(TD) | 105 | ||||
| SEAL STRENGTH | |||||
| MD/Hot Wire Seal | N/15mm | F88 | 13 | 16.2 | 19.5 |
| TD/Hot Wire Seal | 13 | 17 | 20 | ||
| COF(Film To Film) | |||||
| Dynamic | D1894 | 0.2 | |||
| Static | 0.18 | ||||
| Max Storage Temperature | ℃ | 35 | 0.22 | 0.2 | |
Packaging Details:
1. Wrap the film roll with transparent POF film: dust-proof.
2. Put paperboard and plastic cover at two edges of the roll: protect the paper core and the edges of POF film.
3. Put the roll in one quality carton: protect the POF film.
4. Put packed cartons on pallets, and wrap the pallets well by stretch film on pallet machines.
5. Put pallets in a container, use rope, and airbag to fix the pallets.
FAQ:
Q40:How to deal with the after-sales problem?
A40:Once you feedback the film problems, we will deal with it and give you the solution as soon as possible.
Q41:Do you have your research and development team?
A41:Yes, we have.
Q42:Can you do perforation free for me?
A42:Yes, we can do maximum 10 lines of perforation for free.
Q43:I want to use this film to package cup noodles, what kind of film do you recommend?
A43:We recommend high speed packing polyolefin shrink film. It’s a film designed for cup noodles package.
