flat type Low Temperature Cross Linked Film
Product Name | Low Temperature Cross Linked Shrink Film | ||||
Color | Transparent | ||||
Available thickness | 12,15,19um | ||||
Type | Perforated No-perforated | ||||
Available width | Single Wound:200mm-3200mm Center Folded:150mm-1000mm | ||||
MOQ | 2000kg | ||||
Delivery time | 7-10days/20GP,10-15days/40GP | ||||
Packing | One roll in one box,all boxes will be packed with plywood pallets | ||||
Application | Low temperature cross Linked film is a kind of high transparency, excellent sealing strength and soft shrinkage film, which has the characteristics of low shrinkage and can shrink quickly at low temperature,it is Ideal heat shrink film for packaging chocolate and other products. The effect of low temperature shrinkage can also protect the heat sensitive products,it is suitable for all types shrinking machines. | ||||
Physical Properties | |||||
Test Item | Unit | Astm Test | Typical Values | ||
THICKNESS | μm | 12 | 15 | 19 | |
OPTICS | |||||
Haze | D1003 | 2 | 2.2 | 2.4 | |
Gloss @ 45Deg | D2457 | 80 | |||
Clarity | D1746 | 90.1 | |||
SHRINKAGE PROPERTIES | MD | TD | |||
Free Shrinkage 90℃ | % | D2732 | 20 | 25 | |
100℃ | 35 | 40 | |||
110℃ | 59 | 60 | |||
120℃ | 78 | 79 | |||
TENSILE | |||||
Tensile Strength(MD) | N/mm² | D882 | 100 | ||
Tensile Strength(TD) | 100 | ||||
Elongation(MD) | % | 110 | |||
Elongation(TD) | 105 | ||||
SEAL STRENGTH | |||||
MD/Hot Wire Seal | N/15mm | F88 | 13 | 16.2 | 19.5 |
TD/Hot Wire Seal | 13 | 17 | 20 | ||
COF(Film To Film) | |||||
Dynamic | D1894 | 0.2 | |||
Static | 0.18 | ||||
Max Storage Temperature | ℃ | 35 | 0.22 | 0.2 |
Packaging Details:
1. Wrap the film roll with transparent POF film: dust-proof.
2. Put paperboard and plastic cover at two edges of the roll: protect the paper core and the edges of POF film.
3. Put the roll in one quality carton: protect the POF film.
4. Put packed cartons on pallets, and wrap the pallets well by stretch film on pallet machines.
5. Put pallets in a container, use rope, and airbag to fix the pallets.
FAQ:
Q10: how can we guarantee quality?
A10: Always a pre-production sample before mass production;
Always final Inspection before shipment.
Q11:which certification do you have at now:
A11:ISO,MSDS,SGS report,ROHS report,Reach report and so on.
Q12:where are you located ?
A12:we located in Jiangyin city of Jiangsu province,very close to shanghai city,
It will just spend 2hours by car to shanghai city.
Q13:what’s your minimum order quantity?
A13: 2000kgs
Q14:How long can I expect to get the sample?
A14:within 5-7days
Q15:What are your main products?
A15: our main products are Polyolefin shrink film,Cross linked film and printed film.
