single layer cross linked film
Jiangyin Yijia Packaging Material Co.,Ltd was established in 2006. It is an enterprise that produces and sells shrink film and cross linked shrink film. Our products are known for their high quality, versatility and environmental friendliness. Our products are exported to Southeast Asia, North and South America, Europe, Middle East and other regions. The annual production capacity can reach 20,000 tons. On the basis of strict quality control, Jiangyin Yijia Packaging Material Co.,Ltd produces the products, which can meet European and American market standards and is well received by customers all over the world. With an innovative attitude, we provide all customers with the best products and services. We sincerely look forward to long-term cooperation with you.

Product Description

Standard Cross Linked Pilm Physical Properties | |||||
Test Item | Unit | Astm Test | Typical Values | ||
Thickness | um | 12 | 15 | 19 | |
Haze | D1003 | 2.2 | 2.5 | 3 | |
Gloss@45Deg | D2457 | 85 | 85 | 85 | |
Clarity | D1746 | 94 | 94 | 91 | |
MD | TD | ||||
Free Shrinkage 100℃ | % | D2732 | 15 | 15 | 25 |
110℃ | % | D2732 | 38 | 38 | 45 |
120℃ | % | D2732 | 65 | 65 | 66 |
130℃ | % | D2732 | 81 | 81 | 80 |
Tensile Strength(MD) | N/mm2 | D882 | 140 | ||
Tesnsile Strenght(TD) | N/mm2 | D882 | 135 | ||
Elongation(MD) | % | D882 | 90 | ||
Elongation(TD) | % | D882 | 90 | ||
Hot Wire Seal (MD) | N/15mm | F88 | 12.5 | 15.2 | 18..5 |
Hot Wire Seal(TD) | F88 | 13 | 16.6 | 19 | |
COF(Film to Film) | |||||
Dynamic | D1894 | 0.16 | 0.18 | 0.2 | |
Static | D1894 | 0.16 | 0.17 | 0.2 | |
Max Storage Temp. | ℃ | 32 |
Packing & Shipping

FAQ
Q:What temperature does Polyolefin shirnk film shrink at?
A:Generally pof shrinks at around 150 degrees c. it is important to understand that the heat of the tunnel, the length of the tunnel, the speed through the tunnel and the type of pack being covered all need to be controlled to get the perfect shrink.
Q:Do I need special ventilation for pof?
A:No. Because of the film, the ventilation needs to be appropriate for the heat tunnel though.
Q:How to choice the thickness of the pof film??
A:Generally speaking, the heavier the item being packed, the thicker the film.
